Stainless Steel Sheet Metal Gauge

Stainless steel sheet metal gauge refers to the thickness of stainless steel sheets as measured by gauge numbers, which is a standard way of specifying the thickness of metal materials. The gauge number is inversely related to the sheet thickness-lower gauge numbers indicate thicker sheets, while higher numbers represent thinner sheets.Stainless steel sheet metal gauge numbers provide a standardized way to specify the thickness of sheets. Understanding these gauges helps in selecting the appropriate material for various applications based on strength, weight, and design requirements.

Gauge 10:

Thickness: 0.1345 inches (3.41 mm)

Applications: Heavy-duty applications such as structural components and industrial machinery.

Gauge 12:

Thickness: 0.1046 inches (2.66 mm)

Applications: Heavy equipment, industrial panels, and protective coverings.

Gauge 14:

Thickness: 0.0747 inches (1.90 mm)

Applications: HVAC ductwork, industrial enclosures, and structural panels.

Gauge 16:

Thickness: 0.0598 inches (1.52 mm)

Applications: Light structural components, cabinetry, and appliance parts.

Gauge 18:

Thickness: 0.0478 inches (1.21 mm)

Applications: Kitchen equipment, decorative panels, and automotive parts.

Gauge 20:

Thickness: 0.0359 inches (0.91 mm)

Applications: Thin-walled enclosures, appliance panels, and decorative applications.

Gauge 22:

Thickness: 0.0312 inches (0.79 mm)

Applications: Lightweight panels, decorative trim, and thin-walled enclosures.

Gauge 24:

Thickness: 0.0239 inches (0.61 mm)

Applications: Lightweight enclosures, interior paneling, and decorative applications.

Gauge 26:

Thickness: 0.0179 inches (0.45 mm)

Applications: Very thin applications, such as appliance parts and lightweight panels.

Gauge 28:

Thickness: 0.0149 inches (0.38 mm)

Applications: Specialized applications requiring very thin stainless steel, such as electronics enclosures.
