24 Gauge Stainless Steel Sheet
24 gauge stainless steel sheets offer a lightweight and flexible solution for a variety of applications, from architectural features and kitchen equipment to automotive components and consumer products. Their corrosion resistance, ease of fabrication, and aesthetic appeal make them suitable for many environments and uses. By understanding the specific properties and applications, as well as considering fabrication and cost factors, you can effectively utilize 24 gauge stainless steel sheets in your projects to achieve durable and high-quality results.
Specification
|
Product Name
|
Stainless steel sheet
|
|
Steel Grade
|
201 304 304L 316 316L 316Ti 309 310 321 410 420 430 440 630 2205 2507 17-7PH 17-4PH
Monel 400 C276 ect
|
|
Standard
|
JIS/SUS/GB/DIN/ASTM/AISI/EN
|
|
Technique
|
Cold rolled; Hot rolled
|
|
Processing
|
Decoiling, Bending, Punching, Cutting, Polishing, Welding
|
|
Thickness
|
0.635mm
|
|
Standard size
|
1000*2000mm, 1219*2438mm, 1250*2500mm, 1500*3000mm, 1800*6000mm, as required
|
|
Surface
|
2B, NO.1, NO.4, HL, Mirror, 8K, Embossing, Satin, brushed, colored with PVC/PE/Laser film
|
|
Lead time
|
7 days in stock, 15-20 days for customized size
|
|
Package
|
Wooden Pallet or according to customer's requirements
|
Certificate
Factory
Transportation
Physical Properties
Thickness:
Measurement: Approximately 0.635 millimeters (0.025 inches).
Density:
Typical Range: About 7.93 g/cm³ (for both 304 and 316 stainless steel).
Melting Point:
Range: Between 1370°C to 1400°C (2500°F to 2550°F).
Thermal Conductivity:
304 Stainless Steel: Approximately 16.2 W/m·K.
316 Stainless Steel: Approximately 16.3 W/m·K.
Specific Heat Capacity:
Range: About 500 J/kg·K.
Coefficient of Thermal Expansion:
Range: About 17.2 x 10⁻⁶ /°C for 304 and 16.0 x 10⁻⁶ /°C for 316.
Mechanical Properties
Tensile Strength:
304 Stainless Steel: Approximately 515 MPa (75 ksi).
316 Stainless Steel: Approximately 485 MPa (70 ksi).
Yield Strength:
304 Stainless Steel: Approximately 205 MPa (30 ksi).
316 Stainless Steel: Approximately 205 MPa (30 ksi).
Elongation at Break:
Range: Approximately 40% for both 304 and 316 grades.
Hardness:
Rockwell B Hardness: Around 70-80 HRB.
